Submersible Borehole Deep Well Drainage Pump

Hydroman^® Submersible Borehole Deep Well Drainage Pump Overview

Hydroman^® Submersible Borehole Deep Well Drainage Pump also called submersible borehole water pump, is specially designed for deep water lifting applications such as agricultural irrigation, drinking water supply, industrial use, and municipal systems. This pump is fully submersible, integrating a water-filled or oil-filled motor with a multi-stage centrifugal impeller system to deliver water from deep wells, boreholes, or underground reservoirs.

With corrosion-resistant materials, low energy consumption, and high lifting performance, it is ideal for locations where surface pumping is impractical or inefficient.

Hydroman^® Submersible Borehole Deep Well Drainage Pump Technical Specifications

• Well Dia.: 100-550mm
• Outlet dia.: 1.5-10inch
• Capacity: 5-1000m3/hr
• Head: 10-400m
• Temp.: 0-90℃
• PH Value: 6.5-8.5
• Sand Content: up to 0.01%
• Materials: Cast iron, SS304, SS316L, SS904, Bronze etc

Hydroman^® Submersible Borehole Deep Well Drainage Pump Feature

• Operational depth: 50–800 meters
• Multi-stage impeller system ensures consistent pressure at extreme depths
• High-chrome alloy impellers resist abrasion from sand and silt

• Pump housing: Stainless steel (AISI 304/316) or corrosion-resistant cast iron

• Motor protection: IP68-rated, oil-filled cooling system for 24/7 operation

• Double mechanical seals (SiC/SiC) with 0.5MPa pressure rating

Hydroman^® Submersible Borehole Deep Well Drainage Pump Applications

• Large-scale farmland irrigation

• Drought-resistant water supply systems

• Livestock watering
• Deep well drinking water supply

• Mine dewatering and process water

• Geothermal energy projects
