Submersible Centrifugal Dredging Mud Pump to Pumping Silica Sand

Hydroman^® Submersible Centrifugal Dredging Mud Pump to Pumping Silica Sand is a high-performance, heavy-duty pump engineered for the direct transfer of abrasive silica sand, silt, and mineral-rich slurries from underwater or submerged environments. With a robust centrifugal mechanism, high-chrome wear-resistant parts, and optional agitators, hydroman^® submersible slurry pump is the ideal solution for sand mining, silica processing, and dredging operations in challenging conditions.

Hydroman^® Submersible Centrifugal Dredging Mud Pump to Pumping Silica Sand Technical Specifications

• Size: 50-400mm

• Capacity: 7-4000m3/h

• Head: 7-125m

• Power: 0.75-800kw

• Max. particle: 120mm

• Agitator or Cutter heads: Available

• Materials: High chrome, Hyperchrome, SS304, SS316L, Duplex SS etc

Hydroman^® Submersible Centrifugal Dredging Mud Pump to Pumping Silica Sand Structural Design

• Pump Body -  Made of Cr27 high-chrome alloy with enhanced wall thickness for abrasion resistance.
• Impeller -  Semi-open or closed impeller (depending on model), capable of handling high solid content.
• Agitator - Mounted on motor shaft, agitates the sediment around suction to ensure continuous feeding.
• Mechanical Seal - Double mechanical seal with an oil isolation chamber for motor protection.
• Motor - Submersible IP68-rated motor, filled with coolant or oil, with thermal and moisture protection.
• Power Cable - Waterproof, abrasion-resistant cable with molded cable entry for sealing integrity.

Hydroman^® Submersible Centrifugal Dredging Mud Pump to Pumping Silica Sand Installation Types

• Mobile Free-Hanging – Suspended from crane, dredger arm, or boom – ideal for sand mining barges.

• Excavator-Mounted – Welded bracket for mounting on excavator arms, hydraulic or electric power.

• Fixed Wet Well (Guide Rail System) – Mounted in industrial pits or tailings ponds; retractable via rails for maintenance.

• Floating Platform Mounted – For continuous dredging in lakes, rivers, ports – pump fixed under floating pontoon.

Hydroman^® Submersible Centrifugal Dredging Mud Pump to Pumping Silica Sand Optional Systems

• Jet Ring / Water Flushing Ring
• Side Cutter Heads
• Cooling Jacket
• Control Panel
• Variable Frequency Drive


Hydroman^® Submersible Centrifugal Dredging Mud Pump to Pumping Silica Sand Typical Applications

• Silica sand mining washing plant feed

• Underwater sand extraction (rivers, lakes, coasts)

• Tailing pond dredging in quartz processing plants

• Dewatering silty construction foundations

• Industrial sand slurry handling (glass or ceramics industries)
