Submersible Deep Well Pump for Agricultural Irrigation and Groundwater Extraction

Hydroman^® Submersible Deep Well Pump for Agricultural Irrigation and Groundwater Extraction Overview

Hydroman^® Submersible Deep Well Pump for Agricultural Irrigation and Groundwater Extraction is specially designed for extracting clean water from deep boreholes, wells, and reservoirs, making it ideal for agricultural irrigation, rural water supply, and groundwater lifting. Installed directly into the water source, the pump eliminates the need for priming and operates quietly and efficiently even at high depths.

Built for long-term submerged operation, it features a multi-stage centrifugal impeller design, corrosion-resistant materials, and energy-efficient submersible motors to deliver consistent high head and large flow rates for demanding agricultural and irrigation systems.

Hydroman^® Submersible Deep Well Pump for Agricultural Irrigation and Groundwater Extraction Technical Specifications

• Power Range                          3 – 250kW
• Voltage                                   380V / 415V / 660V, 3-Phase
• Flow Rate                                Up to 1000 m³/h
• Max Head                               Up to 400 meters
• Borehole Diameter                 100-550mm (customized on request)
• Impeller Type                          Multistage Centrifugal
• Material Options                     Cast Iron / SS304 / SS316 / Bronze
• Motor Cooling                         Water-Filled or Oil-Filled
• Max Sand Content                   ≤ 0.25%
• Liquid Temperature Range      0°C – 90°C
• Installation Depth                    Up to 300 meters

Hydroman^® Submersible Deep Well Pump for Agricultural Irrigation and Groundwater Extraction Typical Applications

• Agricultural Irrigation Systems
Providing high-pressure water for drip, sprinkler, and flood irrigation.

• Groundwater Extraction
Reliable lifting of fresh water from deep aquifers in rural and desert regions.

• Farm and Ranch Water Supply
Supplying clean water for livestock, crop irrigation, and domestic use.

• Municipal and Community Wells
Supplying water to villages, schools, and small towns.

• Industrial Process Water Supply
Groundwater extraction for manufacturing, mining, or power plants.

Hydroman^® Submersible Deep Well Pump for Agricultural Irrigation and Groundwater Extraction Certifications

• CE Certification
Conforms to European Union safety, health, and environmental protection requirements.

• ISO 9001:2015 – Quality Management System
Ensures consistent quality control throughout design, production, and delivery.

• ISO 14001:2015 – Environmental Management System
Demonstrates commitment to environmentally responsible manufacturing.

• CCC Certification (China Compulsory Certification) (if applicable)
Required for electrical equipment sold in the Chinese domestic market.

• Test Reports Available
Hydraulic performance test, insulation resistance, and motor testing reports available upon request.

• Customized Certifications
Can be provided upon request for projects requiring UL, SGS, DNV or Bureau Veritas, depending on your regional needs.
