Hydroman® Submersible Drainage Pump for Civil Engineering is designed to provide efficient, continuous dewatering in demanding construction and infrastructure projects. Compact, portable, and highly durable, Hydroman® submersible sewage dirty water pump excels at removing clean or slightly muddy water from building foundations, shafts, tunnels, pits, and other confined spaces.
• Size: 50-600mm
• Capacity: 10-6000m3/h
• Head: 5-62m
• Speed: 750-3550r/min
• Temperature Range: ≤80°C
• Sealing arrangement: Double Mechanical seal
• Motor: 50Hz/60Hz, 110V/220V/380V/440V/460V/660V/1000V
• Materials: Cast iron, SS304, SS316L, Duplex SS, High chrome, Hyperchrome etc
| Model | Capacity (m3/h) | Head (m) | Speed (r/min) | Power (kw) | Efficiency (%) | Weight (kg) |
| 300TWQ600-6-18.5 | 500-750 | 6 | 1470 | 18.5 | 61-69 | 650 |
| 300TWQ600-7-22 | 500-750 | 7 | 1470 | 22 | 61-69 | 660 |
| 300TWQ700-11-30 | 550-1000 | 11 | 980 | 30 | 72-78 | 780 |
| 300TWQ700-14-37 | 550-1000 | 14 | 980 | 37 | 72-78 | 880 |
| 300TWQ700-16-45 | 550-1000 | 16 | 980 | 45 | 72-78 | 1150 |
| 300TWQ700-19-55 | 550-1000 | 19 | 980 | 55 | 70-75 | 1215 |
| 300TWQ1000-20-75 | 800-1400 | 20 | 990 | 75 | 75-82 | 1530 |
| 300TWQ1000-24-90 | 800-1400 | 24 | 990 | 90 | 75-82 | 1650 |
| 300TWQ1000-28-110 | 800-1400 | 28 | 1480 | 110 | 75-82 | 1720 |
| 300TWO1000-35-132 | 800-1400 | 35 | 1480 | 132 | 75-82 | 1800 |
• Heavy-Duty Cast Iron or Stainless Steel Construction
Withstands harsh site environments and ensures long service life.
• Compact and Portable
Easy to install and relocate, ideal for mobile civil works.
• Continuous Operation Capability
Designed for long working hours with built-in cooling and mechanical seal protection.
• Equipped with multiple protections
Stator winding thermal protection, oil chamber oil and water probe protection, leakage protection, cable connection chamber leakage protection, shaft temperature protection, absolute protection for water pump motor
• Discharge of domestic sewage
• Temporary flood discharge
• The sewage system of municipal engineering
• Drainage of public facilities
• Sewage systems in factories and mines
▪ Various drainage systems
• The transportation of other corrosive or non-corrosive and diluting media
