Submersible Grinder Pump for Sewage and Wastewater

Hydroman^® Submersible Grinder Pump for Sewage and Wastewater Overview

Hydroman^® Submersible Grinder Pump for Sewage and Wastewater is a high-performance cutting pump engineered for sewage and wastewater systems that require powerful solids reduction, vertical discharge, and reliable non-clog operation. Designed for pressurized sewer systems, remote wastewater treatment units, and confined sump pits, hydroman^® submersible sludge pump is equipped with a robust grinding mechanism that converts coarse sewage into fine slurry, enabling it to be pumped over long distances through narrow pipelines without risk of clogging.

With its upward (vertical) outlet, this model is particularly well-suited for deep sump wells, retrofit systems, and compact underground chambers where space constraints limit side-discharge installation.

Hydroman^® Submersible Grinder Pump for Sewage and Wastewater Technical Specifications

• Size: 50-600mm

• Capacity: 10-6000m3/h

• Head: 5-62m

• Speed: 750-3550r/min

• Temperature Range: ≤80°C

• Sealing arrangement: Mechanical seal

• Motor: 50Hz/60Hz, 110V/220V/380V/440V/460V/660V/1000V

• Materials: Cast iron, SS304, SS316L, Duplex SS, High chrome, Hyperchrome etc

Hydroman^® Submersible Grinder Pump for Sewage and Wastewater Main Features

• Integrated Grinder/Cutter System

Hardened stainless steel rotating cutter and fixed ring system effectively shreds rags, plastics, sanitary items, and fibrous solids into pumpable slurry.

Prevents clogging and pipe blockage in narrow piping systems.

• Top/Vertical Outlet Design

Upward-facing discharge allows compact installation in tight spaces such as small lift stations, underground sewage pits, and portable sump tanks.

Reduces risk of discharge line obstruction and allows vertical lifting through long riser pipes.

• Efficient Hydraulic Design

Compact, non-clog impeller supports high head and moderate flow, making it suitable for pressure sewage networks and long pipe runs.

Hydroman^® Submersible Grinder Pump for Sewage and Wastewater Top Outlet Advantages

• Installation in narrow-diameter pits

• Direct vertical lifting through risers

• Reduced elbows/fittings, lowering friction loss


Hydroman^® Submersible Grinder Pump for Sewage and Wastewater Structural & Material Details


• Pump Casing: Cast iron or corrosion-resistant stainless steel for durability in aggressive wastewater environments.

• Impeller: Enclosed or semi-open hydraulic impeller paired with the cutting mechanism for efficient slurry movement.

• Motor Housing: IP68 rated; available with Class H insulation, overload protection, and optional moisture sensors.

Hydroman^® Submersible Grinder Pump for Sewage and Wastewater Optional Configurations

• Float switch for automatic level control

• Control panel with thermal relay and alarm

• Explosion-proof motor

• Cooling jacket for low-immersion operation

• Guide rail auto-coupling system with duck foot

• Stainless steel version for acidic or marine use

Hydroman^® Submersible Grinder Pump for Sewage and Wastewater Typical Applications

• Residential and municipal pressure sewage systems

• Commercial buildings with basement waste collection

• Industrial wastewater with fibrous solids

• Toilet and greywater disposal in remote or low-pressure areas

• Resorts, farms, or mobile sanitation systems

• Temporary sewage systems in construction sites
