Hydroman® Submersible Sewage Pump for Seawater with Stainless Steel Material is mainly used in municipal engineering, industrial buildings, hotels, hospitals, civil air defense, mines, etc. Industrial drainage, sewage, wastewater, rainwater and domestic water in cities contain solid particles and various long fabrics.
Hydroman® Submersible Sewage Pump for Seawater with Stainless Steel Material Parameters
Model | Capacity Q (m3/h) | Head H (m) | Speed n (r/min) | Motor Power P (kw) | Eff. η (%) |
40TWQ | 8.4-14.4 | 14-16 | 2900 | 1.5 | 42-70 |
50TWQ | 7-50.4 | 8-36 | 1450-2900 | 0.75-7.5 | 46-62 |
65TWQ | 17.5-44.4 | 11-30.2 | 2900 | 2.2-4 | 39-72 |
80TWQ | 20.3-72 | 5.7-27.5 | 2900 | 2.2-7.5 | 51-75 |
100TWQ | 35-120 | 5.6-38.5 | 1450 | 4-15 | 46-80 |
150TWQ | 49-300 | 5.5-44.5 | 1450 | 5.5-37 | 58-82 |
200TWQ | 110-480 | 5.7-44.5 | 1450 | 11-75 | 63-83 |
250TWQ | 420-840 | 7-35 | 980-1450 | 30-90 | 63-84.5 |
300TWQ | 280-1140 | 6.7-27 | 980-1450 | 45-110 | 68-84.5 |
350TWQ | 700-1800 | 8-40 | 980 | 45-160 | 68-85 |
400TWQ | 1050-2640 | 12-33 | 980 | 55-160 | 71-85 |
500TWQ | 1400-3600 | 9-22.5 | 980 | 110-200 | 72-85 |
600TWQ | 2500-6000 | 8-25 | 590-740 | 110-315 | 65-78 |
Hydroman® Submersible Sewage Pump for Seawater with Stainless Steel Material Features
• Corrosion-Resistant Stainless Steel Construction
The pump is constructed using high-quality stainless steel, ensuring excellent resistance to corrosion, rust, and wear in aggressive environments like seawater. This makes it ideal for long-term use in marine and coastal applications.
• Heavy-Duty Submersible Motor
Equipped with an IP68-rated submersible motor, this pump is designed for continuous submerged operation. The motor is fully protected from water ingress and is capable of operating for extended periods without overheating, ensuring reliable and consistent performance.
• High Solids Handling Capacity
The pump is designed to handle sewage and wastewater containing solid particles, debris, and sludge. With an efficient impeller design, it can pass solids up to 80mm in diameter, making it suitable for sewage treatment applications with high solid content.
• Energy-Efficient Design
This pump is engineered to minimize energy consumption while maintaining high performance. Its energy-efficient motor reduces operational costs over the long term, making it a cost-effective solution for continuous or large-scale pumping operations.
Hydroman® Submersible Sewage Pump for Seawater with Stainless Steel Material Usage
• Marine and Coastal Wastewater Treatment
This pump is ideal for handling sewage, industrial wastewater, and effluent in coastal wastewater treatment plants, desalination facilities, and marine environments.
• Seawater Drainage and Dewatering
Perfect for pumping seawater, stormwater, and floodwater in marine areas, ensuring effective drainage and preventing water accumulation in coastal infrastructure.
• Industrial Wastewater in Coastal Areas
Suitable for industries located near the coast that need to pump wastewater containing solids, including food processing, petrochemical, and chemical plants.
• Marine Floodwater Management
Efficient for managing floodwater and seawater runoff from construction sites, harbors, and ports, where large amounts of water may need to be pumped quickly.
• Ship Sewage and Wastewater Handling
This pump can be used on ships or in ports to manage sewage and wastewater systems, ensuring proper effluent treatment and handling in maritime settings.
For more information for Hydroman® Submersible Sewage Pump for Seawater with Stainless Steel Material to Contact
