TJQ Submersible Slurry Pump

Hydroman^® TJQ Submersible Slurry Pump

equipped with an agitator for coarser slurries that can stirs up settled or compacted solids, which allowing them to easily transfer a very high percentage of solids to water and pumping out sand, sludge and solids in suspension.

Hydroman^® TJQ Submersible Slurry Pump Specifications:
Size: 50-600mm
Capacity: 10-4000m3/h
Head: 8-125m

Max. power: 800kw
Max. particles: 60mm
Max. concentration: 70%
Max. working depth: ≤ 150m
Agitator or Cutterheads: Available
Sealing arrangement: Double mechanical seal
Materials: Hyperchrome alloy, Cast iron, SS304, SS316L, Duplex SS etc

Hydroman^® TJQ Submersible Slurry Pump Key Features

Here are the key features of  TJQ submersible slurry pumps, highlighting what makes them ideal for handling abrasive and high-solids slurries in harsh environments:

▪ Double mechanical seals prevent water intrusion into the motor and oil chamber, requiring no scheduled cleaning.

▪ Hydroman submersible slurry sand pump made by Hi-Chrome material, which very well be ideal for pumping stubborn and settled sediment and solids.
▪ Three-vanes impeller design enables submersible dredging slurry pump to handle liquid concentrations up to approximately 70% and achieve a sand discharge rate of up to 30%.

▪ Submersible slurry sludge pump builded an agitator, and with side cutters, cutter head and water jet ring option,  dedicated deal with very hard solid sediments.

▪ Hydroman submersible mud slurry pump equipped with low speed motor, small wear, long service life.

Where field will use Hydroman^® TJQ Submersible Slurry Pump？

Hydroman^® TJQ Submersible Slurry Pump with high-chrome impeller + agitator for sandy slurry，mixed sediments with concentrations up to 70% like Sand/gravel, mining tailings, coal slurry, industrial waste, etc.
