Name: Submersible Sewage Wastewater Pump
Brand: Hydroman
SKU: 65TWQ4

Submersible Sewage Wastewater Pump

65TWQ4

Hydroman

Size Guide

$3,600.00 $3,800.00

Introduction：

Hydroman^® Submersible Sewage Wastewater Pump specialized for wastewater, water, flood and slurry pumping. And our submersible sewage wastewater pumps are ideal for applications such as sewage treatment plants, municipal sewage systems, industrial wastewater management and residential sewage systems. Submersible sewage wastewater pumps are essential for effective wastewater management.

Type:

Submersible Sewage Pump

Submersible Wastewater Pump

Submersible Dirty Water Pump

Submersible Grinder Pump

Quantity :

Description

Hydroman^® Submersible Sewage Wastewater Pump for Seawater-Resistant Dewatering

Hydroman^® Submersible sewage wastewater pump is a corrosion-resistant submersible pump, specializing in the transportation of wastewater containing solids and fibers, rainwater and untreated sewage. Submersible sewage pump is mainly used in municipal engineering, industrial buildings, hotels, hospitals, civil air defense, mining and other industries.

Hydroman^® Submersible Sewage Wastewater Pump Specificaton:

• Size: 50-600mm
• Capacity: 10-6000m3/h
• Head: 5-62m
• Speed: 750-3550r/min
• Temperature Range: ≤80°C
• Sealing arrangement: Double Mechanical seal
• Motor: 50Hz/60Hz, 110V/220V/380V/440V/460V/660V/1000V
• Materials: Cast iron, SS304, SS316L, Duplex SS, High chrome, Hyperchrome et

Hydroman^® Submersible Sewage Wastewater Pump Advanages:

• Easy installation and maintenance. Hydroman^® sewage pump can be installed freely and is equipped with an automatic coupling device for automatic installation.

• Reliable operation and long life. The device with a sealed motor is tightly coupled with the pump body

• Save installation space. no need to build a special pump room to install the submersible pool, sewage pump and machinery, which can save a lot of land and infrastructure costs.

Hydroman^® Submersible Sewage Wastewater Pump Working Condition：

• Medium temperature should not exceed 60℃

▪ Density ≤1200Kg/m, PH value between 5-9.

▪ During operation, the pump level shall not be lower than the minimum level

▪ Rated voltage 380V or 460V, rated frequency 50Hz or 60Hz.

▪ The maximum diameter of solid particles passing through the pump shall not be greater than 50% of the diameter of the pump outlet.

Hydroman^® Submersible Sewage Wastewater Pump Applications:

▪ Discharge of domestic wastewater
▪ Temporary flood discharge
▪ Sewage system of municipal engineering
▪ Drainage of public facilities
▪ Sewage system of factories and mines
▪ Various drainage systems
▪ Transport of other corrosive or non-corrosive and dilute media

Pls contact us for Hydroman^® Submersible Sewage Wastewater Pumps more information and prices:
