Hydroman® Submersible Slurry Mud Sewage Pump for Waste Water is specially engineered to handle abrasive, high-viscosity fluids containing sand, sludge, slurry, and solid particles. It is ideal for wastewater treatment, industrial slurry transfer, mining pits, and municipal sewage systems. Built with robust materials and a non-clogging hydraulic design, hydroman® vertical stainless steel sludge centrifugal pump offers excellent resistance to wear and corrosion, ensuring continuous and reliable operation in harsh conditions.
Hydroman® Submersible Slurry Mud Sewage Pump for Waste Water Performance Parameters
Model | Capacity | Head | Speed | Power | Efficiency (%) | Weight (Kg) |
250TWQ400-7-15 | 300-600 | 5-9 | 1460 | 15 | 62-75 | 450 |
250TWQ400-10-18.5 | 300-600 | 7-12 | 1470 | 18.5 | 68-75 | 550 |
250TWQ400-13-22 | 300-600 | 9-16 | 1470 | 22 | 60-73 | 580 |
250TWQ500-10-30 | 400-700 | 8-15 | 980 | 30 | 70-78 | 700 |
250TWQ500-16-37 | 400-700 | 14-18 | 980 | 37 | 70-78 | 780 |
250TWQ500-20-45 | 400-700 | 16-22 | 980 | 45 | 70-78 | 1050 |
250TWQ500-25-55 | 400-700 | 19-28 | 980 | 55 | 72-74 | 1115 |
250TWQ600-28-75 | 500-800 | 23-31 | 1480 | 75 | 70-75 | 1480 |
250TWQ600-34-90 | 500-800 | 27-37 | 1480 | 90 | 70-75 | 1580 |
250TWQ600-40-110 | 500-800 | 33-43 | 1480 | 110 | 68-73 | 1650 |
25T0WQ600-50-132 | 500-800 | 40-53 | 1480 | 132 | 68-73 | 1710 |
Hydroman® Submersible Slurry Mud Sewage Pump for Waste Water Structures Description
• Motor: Of H class insulation,max.working temperatures 155℃, and of a protective grade IP68 with the effective seal.
• Impeller: With the optimized design, the impeller will not be blocked up when to transport liquid with its optimum flow and rate and the maximum efficiency. There are suitable impellersat choice for every point of working condition.
• Pump casing: Use the know-how of CAD/CAM to make it of max. efficiency and min wearability.
• Bearing: Imported SKF of NTN bearing, which, with a reasonable configuration, can oxtend the duration of the pump.
• Mechanical seal: Use Bogman mechanic al seal of Germany, two ways of the seal are in series with each other and individually work to separate the motor from the pump seal to provide the motor with a dual protection.
The sealing material on the pump side is tungsten carbide/tungsten carbide while on the motor side, graphite/silicon carbide.
• Shaft: The pump is coaxial with the motor and the sealing device on the end of the shaft prevents against contacting with the medium to protect is from corrosion.
The as short as possible designed stretched rotating shaft can be reduced with its deflection and vibration, extend the duration of both mechanical seal and bearing and lower the noise at running.
Hydroman® Submersible Slurry Mud Sewage Pump for Waste Water Optional Configurations
• Built-in agitator or jet ring
• Stainless steel variant for corrosive fluids
• Auto-coupling guide rail system
• Explosion-proof motor version (Ex d)
• Dry-run and overheat protection
• PLC control panel with remote monitoring
Hydroman® Submersible Slurry Mud Sewage Pump for Waste Water Applications
• Mining Dredging: Slurry transfer, tailings management, and dewatering.
• Wastewater Treatment: Thickened sludge, grit, and primary effluent handling.
• Construction Sites: Mud pumping from excavations, tunnels, and trenches.
• Industrial Processes: Chemical slurry transfer, coal ash handling, and pulp/paper waste.
• Agriculture: Manure and silage leachate pumping.
