High Pressure Dewatering Submersible Drainage Pump

Hydroman^® High Pressure Dewatering Submersible Drainage Pump Overview

Hydroman^® High Pressure Dewatering Submersible Drainage Pump is an industrial-grade pump specifically engineered to deliver high head, high efficiency water discharge under challenging site conditions. Featuring a compact submersible structure, corrosion- and abrasion-resistant materials, and a hydraulically optimized impeller design, this pump is ideally suited for deep excavation projects, underground drainage, mining pits, and emergency flood control.
Engineered for reliability and durability, Hydroman^® pump is capable of continuous operation in aggressive environments and is designed for long service life with minimal maintenance.

Hydroman^® High Pressure Dewatering Submersible Drainage Pump Technical Specifications

• Capacity:                     up to 160m³/h
• Head:                           up to 57 meters
• Power:                         1.5kW (2HP) to 15 kW (20HP)
• Frequency:                  50Hz, 60Hz
• Protection class:        IP68
• Water temperature:    up to 40℃
• Max. water depth:      25m

Hydroman^® High Pressure Dewatering Submersible Drainage Pump Benefits:

• The motor and pump housing are constructed from rigid cast iron, ensuring long-lasting durability and structural integrity in harsh operating environments.

• High-pressure mechanical seals (up to 0.5 MPa) significantly increase the maximum submersion depth, enhancing operational safety and reliability under deep water conditions.

• The semi-open impeller is manufactured from high chrome alloy, offering exceptional wear resistance. It is paired with a wear plate made from ductile cast iron, further extending service life under abrasive conditions.

• Effective motor cooling is achieved via an integrated discharge passage, which is cast as part of the motor housing to ensure optimal thermal management.

• Top discharge outlet design allows for space-saving installation, making the pump ideal for narrow wells, pits, or confined drainage chambers.

Hydroman^® High Pressure Dewatering Submersible Drainage Pump Application Fields

• Civil Construction – Foundation drainage, bridge shaft dewatering, building basement projects

• Mining Operations – Open pit and underground mine dewatering

• Tunnel Engineering – Water removal in metro, rail, and highway tunnel boring sites

• Municipal Projects – Stormwater and emergency flood control

• Industrial Drainage – Process water handling, sump water removal
